GOMIN® High-Temperature Protection
The GOMIN High-Temperature Resistant Coating Family: 400°C to 1800°C
Three engineered series, one supplier. Waterborne silicone, inorganic-organic ceramic and rare-earth composite systems for boilers, kilns, chimneys, tanks and exhaust hardware operating at continuous extreme heat.
Request a Grade Recommendation
What Is the GOMIN High-Temperature Resistant Coating Family?
The GOMIN high-temperature resistant coating family is a coordinated range of heat-stable protective coatings engineered to solve one problem: metal equipment that must survive sustained heat, thermal cycling and corrosion at the same time. Rather than forcing a single chemistry to cover every duty, Dalian GOMIN Special Coating Co., Ltd. divides the range into three temperature bands — 400°C to 800°C, 800°C to 1200°C and duties up to 1800°C — so that each grade is matched to the real working conditions of the equipment it protects.
The lower band is built on waterborne pure silicone resin and waterborne heavy-duty anti-corrosion technology. The middle band moves to an inorganic-organic composite ceramic structure with multi-layer flake sealing. The upper band adds rare-earth micro-powders and silicon carbide fillers that penetrate the metal grain boundaries to form a chemical anchor, so the coating stays bonded even when it is applied over rusted steel. Together the three series cover applications from home appliances and cookware to automotive exhausts, chemical storage tanks, desulfurization equipment, petrochemical high-temperature plant, metallurgical kilns, chemical pipelines, power boilers, high-wear corrosive components and chimney interiors.
Because all three series are supplied by one manufacturer, specifiers can standardise on a single coating partner across an entire plant, using the same surface-preparation philosophy, the same application equipment and a consistent quality system. Every grade is tested against recognised GB/T methods, and mechanical properties such as pencil hardness, salt-spray resistance and thermal-shock behaviour are used to select the right product rather than marketing claims.
The Three Series at a Glance
400°C – 800°C Series
Waterborne, environmentally advanced protection with a long service life for everyday high-temperature equipment.
Flagship grades: GM-3040 waterborne pure silicone resin coating and GM-3041 waterborne heavy-duty anti-corrosion paint.
- Long-term 800°C, short-term peak 1500°C
- 5H pencil hardness, 2000-hour salt spray without corrosion
- Zero toluene and xylene, low VOC
- Service life up to 30 years
800°C – 1200°C Series
Extreme protection that pushes past the usual thermal boundary of organic coatings.
Flagship grades: GM-812 ceramic anti-corrosion coating and GM-1280 nano-ceramic coating.
- Instant peak resistance up to 1280°C
- 600°C quench with no cracking
- Inorganic-organic composite, multi-layer flake sealing
- Blocks acids, alkalis, salts and corrosive gases
Up to 1800°C Series
Rare-earth and silicon carbide chemistry for the harshest heat, wear and corrosion duties.
Flagship grades: GM-846 rust-tolerant anti-coking coating and GM-813 composite ceramic coating.
- Long-term ratings in the 1400°C – 1800°C band
- 7H hardness, smooth self-cleaning surface
- Impact and organic-solvent resistant
- Applies over rusted steel, chemical anchoring
Why Industrial Teams Choose This Family
Full Temperature Coverage
From 400°C to 1800°C, one coherent range removes the need to source separate chemistries for each temperature zone of a plant.
Long Service Life
Nano-ceramic technology and multi-layer sealing structures outlast conventional high-temperature paints, with a service life up to 30 years in the lower band.
Environmental Compliance
Waterborne, low-toxicity formulations with zero toluene and xylene support green production and help meet global VOC regulations.
Application Friendly
Spray, brush, roller or airless spray, with a wide curing window and ambient surface dry options that shorten downtime.
Thermal Shock and Rust Tolerance
Grades endure rapid heating and cooling — 600°C quench without cracking — and the upper band bonds directly onto rusted steel.
Verified to Standards
Heat, hardness and corrosion performance are tested to GB/T methods, so specifications rest on measurable results.
Series Comparison
| Series | Temperature Range | Flagship Grades | Binder Chemistry | Hardness | Typical Duty |
|---|
| 400°C – 800°C | 800°C long term / 1500°C short term | GM-3040, GM-3041 | Waterborne pure silicone resin | 5H | Appliances, cookware, exhausts, desulfurization |
| 800°C – 1200°C | Up to 1280°C instant peak | GM-812, GM-1280 | Inorganic-organic ceramic composite | — | Petrochemical plant, kilns, chemical pipelines, boilers |
| Up to 1800°C | 1400°C – 1800°C long term | GM-846, GM-813 | Rare-earth micro-powder + silicon carbide composite ceramic | 7H | Tanks, high-wear corrosive parts, chimney interiors |
Verified Performance Indicators
| Property | Value | Applies To |
|---|
| Long-term heat resistance | 800°C / 1400°C – 1800°C | 400°C–800°C series / up to 1800°C series |
| Short-term peak resistance | 1500°C / 1280°C | 400°C–800°C series / 800°C–1200°C series |
| Thermal shock | 600°C quench, no cracking | 800°C–1200°C series |
| Pencil hardness | 5H / 7H | 400°C–800°C series / up to 1800°C series |
| Salt spray resistance | 2000 hours without corrosion | 400°C–800°C series |
| Solvent content | Zero toluene and xylene, low VOC | Waterborne grades |
| Dry time | Within 24 hours | Upper band, airless spray |
Values reflect the manufacturer’s published test data for guidance and should be confirmed against the specific grade and service conditions before specification.
Where the Family Is Used
Energy and Petrochemical
Desulfurization equipment, petrochemical high-temperature plant, chemical pipelines, power boilers and chimney interiors where heat and acid gases act together.
Metallurgy and Heavy Industry
Metallurgical kilns, furnace shells, hot ducting and high-wear, high-corrosion mechanical components that see repeated thermal cycling.
Equipment and Consumer Hardware
Home appliances, cookware, automotive exhaust systems and chemical storage tanks that need durable heat and corrosion protection in daily service.
Application and Curing Summary
| Step | Guidance Across the Family |
|---|
| Application methods | Spray, brush or roller; airless spray for the upper band |
| Substrate condition | Clean steel; upper-band grades tolerate residual rust |
| Curing | Ambient cure or short stoving for waterborne grades; ambient surface dry followed by high-temperature densification for ceramic grades |
| Dry time | Airless-sprayed upper-band coating dries within 24 hours |
Safety Precautions
- Work in a ventilated area and wear suitable gloves, eye protection and respiratory protection during mixing and spraying.
- Avoid contact with skin and eyes; wash thoroughly after handling.
- Store containers sealed in a dry, cool location away from ignition sources.
- Follow the product-specific technical data sheet and local regulations for waste disposal of containers and overspray.
Frequently Asked Questions
Which series should I choose for my working temperature?
Use the 400°C to 800°C series for sustained service in that band, the 800°C to 1200°C series for duties around the 1200°C class with thermal cycling, and the up-to-1800°C series for the most severe heat, wear and corrosion, such as chimney interiors and chemical tanks. If a single application spans more than one band, share the equipment details and our team will confirm the grade.
Can these coatings be applied over existing rust?
The upper band is specifically designed for it. GM-846 combines rare-earth micro-powders with silicon carbide fillers that penetrate the metal grain boundaries and form a chemical anchor, so a rust-tolerant coating can still deliver long-term protection. Best practice is still to remove loose scale and contamination before application.
How is heat resistance verified?
Grades are tested against recognised GB/T methods, including heat-resistance testing for the 800°C class. Thermal-shock behaviour is confirmed by a 600°C quench without cracking, and corrosion performance by 2000-hour salt spray testing on the waterborne series.
What curing conditions are required?
Waterborne grades cure at ambient temperature or with short stoving, which keeps shop throughput high. Ceramic grades are formulated to surface-dry at ambient temperature and then densify into a hard film under high-temperature service, allowing flexible scheduling around shutdown windows.
Are the waterborne grades really free of toluene and xylene?
Yes. The 400°C to 800°C series is waterborne, contains zero toluene and xylene and delivers low VOC emissions, helping plants meet tightening environmental regulations without sacrificing the 800°C long-term rating, 5H hardness or 2000-hour salt-spray resistance.
Do you provide application support and grade selection?
Our technical team supports surface-preparation planning, application method selection, curing schedules and grade selection across all three series. Send us your equipment type, operating temperature, cycle profile and corrosion environment for a recommendation and samples.
Unlock a New Era of High-Temperature Protection
Tell us your temperature band and duty, and we will match the right GOMIN series. Dalian GOMIN Special Coating Co., Ltd. supplies the full 400°C to 1800°C family with technical support from selection to application.
