GOMIN High-Temperature Coating Series
Engineered for Extreme Heat: 400°C to 800°C Premium Thermal Protection with 1500°C Short-Term Limit
Product Overview
The GOMIN High-Temperature Coating Series represents the pinnacle of thermal protection technology, engineered by Dalian Gomin Special Coating Co., Ltd. for extreme-heat industrial applications. This comprehensive series features two specialized formulations — GM-3040 (Water-based High-Temperature Pure Silicone Resin Coating) and GM-3041 (Water-based High-Temperature Heavy Anti-Corrosion Paint) — designed to deliver uncompromising performance in the most demanding thermal environments.
The GM-3040 formulation utilizes advanced pure silicone resin technology to achieve long-term temperature resistance up to 800°C on metal substrates, with a short-term limit of 1500°C. Its water-based, eco-friendly composition contains no toluene or xylene, meeting stringent environmental regulations while providing a 20-30 year comprehensive protection lifespan.
The GM-3041 variant is a two-component heavy anti-corrosion system engineered for aggressive chemical and thermal environments. Operating across a temperature range of -20°C to 600°C, it combines exceptional acid-alkali resistance with 2000-hour salt spray protection, making it the ideal solution for chemical processing facilities, power plants, and energy infrastructure.
Key Features & Advantages
Extreme Temperature Resistance
GM-3040 withstands continuous temperatures up to 800°C with a short-term limit of 1500°C. GM-3041 operates from -20°C to 600°C, providing year-round thermal protection across cryogenic to high-heat conditions.
Eco-Friendly Water-Based Formula
Both formulations are water-based with zero toluene and xylene content, low odor, and full compliance with modern environmental regulations. Safe for indoor and outdoor application without harmful VOC emissions.
Superior Hardness & Adhesion
GM-3040 achieves 4-5H pencil hardness with Grade 0 adhesion (cross-hatch test). GM-3041 delivers 5H Mohs hardness with Grade 0 adhesion (cross-cut tape method), ensuring long-lasting mechanical protection.
Exceptional Corrosion Resistance
GM-3041 withstands 2000 hours of salt spray (5% NaCl) with no change, and 365 days of immersion in 30% sulfuric acid and nitric acid without degradation. GM-3040 provides excellent long-term anti-corrosion and anti-yellowing performance.
Versatile Application Methods
GM-3040 is optimized for spray application with water dilution (5-10%). GM-3041 supports spray, brush, and roller application, offering flexibility across different project requirements and substrate geometries.
Fast Curing & Long Service Life
GM-3040 surface dries in 1 hour (full cure at 220°C in 30 minutes). GM-3041 surface dries in 30-40 minutes. Combined service life of 20-30 years reduces maintenance frequency and lifecycle costs.
Applications & Industries
GM-3040 Target Applications
- Home Appliances: Cookware, ovens, grills, and heating elements requiring food-safe, high-temperature protection.
- Automotive Industry: Engine components, exhaust pipes, mufflers, and catalytic converter housings exposed to sustained high temperatures.
- Industrial Furnaces: Fireplaces, stoves, kilns, incinerators, and heat treatment equipment.
- Electronic Components: Insulation protection for heat-sensitive electronic assemblies and circuit boards.
- Outdoor Metal Surfaces: High-temperature weather-resistant and anti-corrosion protection for exposed structural steel.
GM-3041 Target Applications
- Chemical Industry: Chemical processing pools, acid and alkali storage tanks, desulfurization equipment.
- Energy & Power: Boiler systems, flue gas ducts, heat exchangers, and power plant infrastructure.
- Pipeline Systems: Industrial pipelines requiring heavy anti-corrosion and thermal protection.
- Multi-Substrate Protection: Metal, concrete, and fiberglass-reinforced plastic (FRP) surfaces requiring acid and alkali resistance.
Performance Comparison: GM-3040 vs GM-3041
| Parameter | GM-3040 Pure Silicone Resin | GM-3041 Heavy Anti-Corrosion |
|---|
| Temperature Range | 200°C-600°C (long-term); 1500°C (short-term) | -20°C to 600°C |
| Hardness | 4-5H (pencil hardness) | 5H (Mohs hardness) |
| Adhesion | Grade 0 (cross-hatch test) | Grade 0 (cross-cut tape method) |
| Solid Content | 50%2% (150°C/2h) | 72% |
| Surface Dry Time | 1 hour | 30-40 minutes |
| Full Cure Time | 30 min (at 220°C) | 48 hours (at room temperature) |
| Salt Spray Resistance | Excellent (long-term protection) | 2000h (5% NaCl) no change |
| Acid/Alkali Resistance | Excellent chemical resistance | 365 days immersion no change (30% H2SO4, HNO3) |
| Application Method | Spray (primary) | Spray, brush, roller |
| System Type | Single-component | Two-component (mix ratio 1:0.085) |
Construction & Application Parameters
GM-3040 Application Guidelines
| Parameter | Specification |
|---|
| Substrate Preparation | Degrease and derust; sandblasting enhances adhesion |
| Construction Temperature | 5°C to 40°C (ambient) |
| Dilution | Water dilution 5-10%; stir thoroughly before spraying |
| Curing Method | Room temperature cure (1 week) or 220°C bake for 30 minutes |
| Packaging | 20KG / 200KG drums |
| Storage Temperature | 0°C to 40°C, cool and ventilated |
| Shelf Life | 12 months |
GM-3041 Application Guidelines
| Parameter | Specification |
|---|
| Substrate Preparation | Bare steel: sandblast to 30-45um roughness; other substrates: clean, oil-free |
| Construction Temperature | At least 5°C (ambient) |
| Maximum Humidity | Below 85% RH |
| Mixing Ratio | 1:0.085 (base:curing agent by weight) |
| Pot Life | Use within 12 hours after mixing |
| Recommended Film Thickness | 200-350um |
| Curing Method | Room temperature dry |
| Transport Classification | Non-hazardous goods |
Application Instructions
- Surface Preparation: Ensure all substrates are clean, dry, and free from oil, rust, and contaminants. For GM-3041 on bare steel, sandblast to achieve 30-45um surface roughness.
- Mixing (GM-3041 only): Combine the two components at a ratio of 1:0.085 (base to curing agent by weight). Allow 20-30 minutes for maturation before application. Use within 12 hours.
- Dilution (GM-3040): Add 5-10% water for spray application. Stir thoroughly until uniform. Do not over-dilute.
- Application: Apply using spray (GM-3040 and GM-3041), brush, or roller (GM-3041 only). Ensure uniform coverage across the substrate surface.
- Curing: GM-3040: Allow 1 hour for surface dry; full cure at 220°C in 30 minutes or room temperature in 1 week. GM-3041: Surface dry in 30-40 minutes; full cure in 48 hours at room temperature.
- Multi-Layer Application: For thick-film applications (GM-3041), apply in multiple layers, allowing each layer to surface-dry before applying the next. Target total film thickness of 200-350um.
Important Safety & Storage Notes
- Always test substrate compatibility before full-scale application.
- Avoid application during rain, snow, or adverse weather conditions.
- Stir coating thoroughly before use; clean tools immediately after application.
- In case of eye contact, rinse immediately with copious water and seek medical attention.
- GM-3040: Re-verify performance after long-term storage; high-temperature baking accelerates curing.
- GM-3041: Ensure previous coating is not chalky before recoating; allow 20-30 minutes maturation after mixing.
Frequently Asked Questions
What is the maximum temperature the GOMIN High-Temperature Coating Series can withstand?
GM-3040 withstands continuous temperatures up to 800°C on metal substrates, with a short-term limit of 1500°C. GM-3041 operates across a range of -20°C to 600°C, making it suitable for both cryogenic and high-heat environments. This makes the series ideal for applications ranging from kitchen appliances to industrial furnaces and chemical processing equipment.
Are these coatings environmentally friendly?
Yes. Both GM-3040 and GM-3041 are water-based formulations containing no toluene or xylene, with low odor and full compliance with modern environmental regulations. The water-based formula ensures safe application in both indoor and outdoor environments without harmful solvent emissions.
What is the expected service life of the coating?
GM-3040 provides a comprehensive protection lifespan of 20-30 years, combining wear resistance, impact resistance, salt spray resistance, and anti-yellowing properties. GM-3041 offers 2000-hour salt spray protection and 365-day acid/alkali immersion resistance, ensuring long-term performance in the most aggressive industrial environments.
Can GM-3041 be applied on concrete and fiberglass surfaces?
Yes. GM-3041 is compatible with metal, concrete, and fiberglass-reinforced plastic (FRP) substrates. For bare steel, sandblasting to 30-45um roughness is recommended. Other substrates should be clean, dry, and free from oil contamination. The coating supports spray, brush, and roller application methods for maximum versatility.
What is the mixing ratio for GM-3041 and how long is the pot life?
GM-3041 is a two-component system with a mixing ratio of 1:0.085 (base to curing agent by weight). After mixing, allow 20-30 minutes for maturation before application. The mixed material must be used within 12 hours. Recommended film thickness is 200-350um for optimal performance.
