GOMIN GM-015860 Fluorocarbon (FEVE) Topcoat
Two-Component Crosslinking Fluorocarbon Coating for Ultra-High Weatherability & Chemical Resistance
GM-015860 is a premium two-component crosslinking fluorocarbon coating built on FEVE resin — an alternating copolymer of chlorotrifluoroethylene and vinyl ester — combined with environmentally friendly solvents and a dedicated fluorocarbon curing agent. Mixed at a ratio of base : curing agent = 5 : 1 (with appropriate thinner), it forms a dense, crosslinked fluorocarbon film engineered for structures that must stay beautiful and protected for decades.
With an artificial accelerated aging test record exceeding 3,000 hours, GM-015860 delivers no early yellowing, long retention of initial gloss and color, outstanding water resistance, excellent chemical resistance, strong adhesion and superior easy-clean properties — on concrete, calcium silicate boards, copper doors, aluminum alloys, large steel structures, bridge projects, ships, wind turbine towers and photovoltaic equipment.
Why Choose GM-015860 FEVE Topcoat
3,000 h Accelerated Weathering
Passed artificial accelerated aging beyond 3,000 hours with no blistering, peeling, cracking or chalking. White films retain over 80% of initial gloss (ΔE* ≤ 3.0).
Acid & Alkali Resistance
168 h immersion in 50 g/L H2SO4 and 240 h in saturated Ca(OH)2 solution with no abnormality — engineered for aggressive industrial and marine atmospheres.
Outstanding Water Resistance
168 h water resistance test with no abnormality. The dense fluorocarbon film blocks moisture ingress and protects steel and concrete substrates year after year.
Superior Easy-Clean Surface
Low-surface-energy fluorocarbon film releases dust, grime and graffiti residues — ideal for curtain walls, viaducts and heritage facades that must stay clean with minimal maintenance.
2H Hardness, 2 mm Flexibility
Pencil hardness of 2H combined with a 2 mm bending test result delivers a film that is both scratch-resistant and flexible enough to follow structural movement.
Strong Adhesion, No Early Yellowing
22% fluorine content in the binder locks in color and gloss, while strong crosslink adhesion keeps the film intact on aluminum, steel, copper and inorganic substrates.
Main Technical Parameters
| Item | Technical Specification |
|---|
| Coating Type | Solvent-based FEVE fluorocarbon coating (two-component) |
| Mixing Ratio | Base : Curing agent = 5 : 1 (thinner as appropriate) |
| Fluorine Content in Binder | 22% |
| Hardness | 2H (pencil hardness) |
| Bending Test | 2 mm |
| Theoretical Coverage | Approx. 5 m²/kg |
| Solid Content (Base) | 52 ± 1% |
| Water Resistance | 168 h, no abnormality |
| Acid Resistance (50 g/L H2SO4) | 168 h, no abnormality |
| Alkali Resistance (saturated Ca(OH)2 solution) | 240 h, no abnormality |
| Artificial Accelerated Weathering (3,000 h) — White | No blistering, peeling, cracking or chalking; ΔE* ≤ 3.0, gloss retention ≥ 80% |
| Artificial Accelerated Weathering (3,000 h) — Other Colors | No blistering, peeling, cracking or chalking; ΔE* ≤ 6.0 or as agreed, gloss retention ≥ 50% |
Application Scope
- Heritage building protection & anti-graffiti aluminum curtain walls
- Concrete viaducts & building facades
- Weather-resistant marine canvas & ship structures
- GRP/GRP-urethane (GRPU) doors, windows and frames
- Calcium silicate insulation integrated panels
- Metal doors & windows; copper door clear coats
- Large steel structures & bridge projects
- Wind turbine towers & photovoltaic equipment
Application Instructions
Mixing
Thoroughly stir the base component before use, add the curing agent in the specified ratio (base : curing agent = 5 : 1), and mix again until uniform.
Pot Life
After mixing at 25 °C, use within 4 hours. Higher temperatures shorten the pot life.
Thinning
May be diluted to application viscosity with the recommended thinner. Avoid over-dilution.
Application Conditions
Substrate temperature must be at least 3 °C above the dew point; relative humidity below 85%.
Curing Agent Protection & Tool Cleaning
Seal the curing agent container immediately after opening to prevent moisture ingress and gelling. Clean tools promptly with thinner after use.
Packaging, Storage & Shelf Life
| Item | Specification |
|---|
| GM-015860 Part A (Base) | 20 kg / barrel |
| GM-015860 Part B (Curing agent) | 4 kg / barrel |
| Storage Temperature | 5–35 °C (avoid freezing and direct sunlight) |
| Storage Requirements | Cool, ventilated place; containers tightly sealed, away from heat and ignition sources |
| Shelf Life | 1 year from production date (unopened) |
Safety Protection
- Contains organic solvents; wear masks, gloves, goggles and other protective equipment during application.
- Avoid skin contact and inhalation of solvent vapors. If paint contacts skin, wash immediately with water or a suitable cleaner.
- If splashed into eyes, rinse immediately with plenty of water and seek medical attention.
- Do not swallow. If ingested, seek medical attention immediately.
- Waste paint, wastewater and residues must be disposed of by professional agencies in compliance with local environmental regulations.
Frequently Asked Questions
What substrates can GM-015860 be applied to?
The coating bonds strongly to inorganic surfaces such as concrete and calcium silicate boards, as well as copper doors, aluminum alloys and large steel structures — making it a versatile topcoat for facades, bridges, ships, wind turbine towers and photovoltaic equipment.
How is the two-component coating mixed and used?
Mix base and curing agent at a ratio of 5 : 1 with appropriate thinner, stirring the base thoroughly first. Once mixed at 25 °C, apply the material within 4 hours, as elevated temperatures shorten the pot life.
How does the coating perform against acids and alkalis?
GM-015860 shows no abnormality after 168 h immersion in 50 g/L sulfuric acid and 240 h in saturated calcium hydroxide solution, confirming its resistance to acidic industrial atmospheres and alkaline concrete substrates.
What gloss and color retention can be expected?
In the 3,000 h artificial accelerated weathering test, white films show ΔE* ≤ 3.0 with over 80% gloss retention; other colors show ΔE* ≤ 6.0 (or as agreed) with at least 50% gloss retention — with no blistering, peeling, cracking or chalking.
What coverage does one kilogram provide?
Theoretical coverage is approximately 5 m² per kilogram, depending on substrate roughness, application method and required dry film thickness.
Get a Quote for GM-015860
Protect your next project with a fluorocarbon topcoat engineered for 3,000-hour weathering performance and proven acid & alkali resistance. Contact Dalian Gomin Special Coating Co., Ltd. for technical data, color options, pricing and delivery schedules for GM-015860.
Tel: +86 151 3456 5556 | Web: www.mescocoating.com | Factory: No. 1, Middle 2nd Road, Liaohe, Economic & Technological Development Zone, Dalian, Liaoning, China
